          KY-1Hybrid-5k0-H
          5KW Single-phase Energy Storage Inverter


          product features

          Integrated Design for PV and Energy Storage

          integrate PV and energy storage, equipped with UPS functional, supporting various kinds of batteries.



          Smart switching

          UPS function, on/off gird switch within 10ms.



          Wide voltage input range

          Wide PV voltage input range 120V-500V,wide batteries voltage range 85V-450V



          Safe and Reliable

          IP 65 protection, high Electricity quality, no interference with other equipment.



          Smart

          Small size, light and easy to install, ultra-silent, flexible communications.



          high-efficiency

          Max Efficiency 97.8%, Smart MPPT, tracing efficiency up to 99.99%

          Technical parameter
          Parameter KY-1Hybrid-5k0-H


          Efficiency

          Max.Efficiency >98.2%


          PV Input

          Max. PV input power(W) 7000
          Max. PV input voltage(V) 550
          MPP Operation Voltage Range(V) 120-500
          Max. number of PV strings per MPPT 1/1
          Max. PV input current(A) 12/12
          Short-circuit current of PV input(A) 15/15


          Battery

          Max Input/Output Voltage(V) 450
          Operating Voltage Range(V) 85-450
          Max Charge/Discharge Current(A) 25/25
          Max Input/Output Power(W) 5000/5000
          Battery Type Li-ion/Lead-acid


          AC Input and Output

          Rated Power(W) 5000
          Max. Apparent AC Power(VA) 5000
          Nominal AC Voltage(Vac) 230,1φ(L/N/PE)
          AC Power Frequency(Hz) 50/60
          Max. AC Output Current(A) 21.7
          Power Factor Range ~1 (Adjustable from 0.8 leading to0.8 lagging)
          OutputTHDi(@Nominal Output) <3


          Off-Grid AC Output(Back-up ACOutput)

          Rated Output Power(W) 5000
          Max. Apparent AC Output Power(VA) 5000
          Nominal AC Output Voltage(Vac) 230,1φ(L/N/PE)(N not connect toPE inside)
          AC Power Frequency(Hz) 50/60
          Max. AC Output Current(A) 21.7


          Genaral Data

          Operating Temperature Range -25℃ …+60℃(>45℃ derating)
          Operating Altitude(m) <4000
          Noise(dB) <40
          Topology Transformerless
          Cooling Method Natural convection
          Ingress Protection Rating IP65
          Relative Humidity 0-100%, no condensation
          DC Connection Type MC/Amphenol/Phoenix
          AC Connection Type Plug-in Connector
          Display LCD
          Communication With Portal RS485 (WiFi/GPRS Optinal)
          Communication With BMS CAN
          Communication With Meter RS485
          Mounting Method Wall-mounting bracket
          Dimensions (W*H*D)(mm) 390*500*185
          Weight(Kg) 18


          Certification

          Safety IEC62109-1/-2
          EMC EN61000-6-1/-2/-3,IEC61000
          On-Grid standard AS4777.2,NRS097-2-1:2017
          Download
          Specifications Size Type Down
          Koyoe?Energy?-?Warranty?commitment 36.7KB DOCX
          Koyoe Energy Warranty commitment 435.KB PDF
          KY-1Hybrid User Manual 2.10MB PDF
          KY-1Hybrid-5k0-H datasheet 99.4KB PDF
